Checkmaster SMM

Checkmaster SMM

Designed for automotive and truck crank and cam checks on the factory floor, SMMs have proven that they can take it, decade after decade.

Shaft measurement machines designed to efficiently check lengths, steps, grooves, diameters, run-out and hole locations quickly using standard hard probes. Now used widely for large and small engine shaft components, as well as turbine, transmission, pump, copier and general shaft measuring applications.

To order, call (+1) 716-297-8644

Name Part # Price
Checkmaster 12"
w/o head or tail stock		 SMM-12 WO Request Quote Call to order
Checkmaster 20"
w/o head or tail stock		 SMM-20WO Request Quote Call to order
Checkmaster 25"
w/o head or tail stock		 SMM--25 WO Request Quote Call to order
Checkmaster 30"
w/o head or tail stock		 SMM-30 WO Request Quote Call to order
Checkmaster 40"
w/o head or tail stock		 SMM-40 WO Request Quote Call to order
Checkmaster 50"
w/o head or tail stock		 SMM-50 WO Request Quote Call to order
Checkmaster 60"
w/o head or tail stock		 SMM-60 WO Request Quote Call to order
Name Part # Price
Checkmaster 12"
manual tail stock		 SMM-12 M Request Quote Call to order
Checkmaster 20"
manual tail stock		 SMM-20 M Request Quote Call to order
Checkmaster 25"
manual tail stock		 SMM-25 M Request Quote Call to order
Checkmaster 30"
manual tail stock		 SMM-30 M Request Quote Call to order
Checkmaster 40"
manual tail stock		 SMM-40M Request Quote Call to order
Checkmaster 50"
manual tail stock		 SMM-50M Request Quote Call to order
Checkmaster 60"
manual tail stock		 SMM-60 M Request Quote Call to order
Name Part # Price
Checkmaster 12"
pneumatic tail stock		 SMM-12 P Request Quote Call to order
Checkmaster 20"
pneumatic tail stock		 SMM-20 P Request Quote Call to order
Checkmaster 25"
pneumatic tail stock		 SMM-25 P Request Quote Call to order
Checkmaster 30"
pneumatic tail stock		 SMM-30 P Request Quote Call to order
Checkmaster 40"
pneumatic tail stock		 SMM-40P Request Quote Call to order
Checkmaster 50"
pneumatic tail stock		 SMM-50 P Request Quote Call to order
Checkmaster 60"
pneumatic tail stock		 SMM-60 P Request Quote Call to order
  Measuring Range
Standard
X-Axis Range		 300, 500, 750, 1000 and 1500 mm
12", 20", 30", 40", 50" and 60"
Y Axis Stoke 150 mm (6")
  NOTE: Other sizes available upon request

Linear Accuracy : 0.00018" + 0.000006" per inch
Bandwidth : 4.5 µm + L * 0.150 µm, L in mm)
Single and Dual Axes of measurement Adjustable "V" blocks
Locks on all axes Air operated centers (Optional)
Zero-play fine adjustment on all axes Heidenhain Digital Readout
Bellows covering all guide ways Ball centers (optional)
Full granite base Low profile for easy loading
1-Year CMM warranty
Wide Range of Hard Probes Air Operated Centers
Isolation Pads Height Adjustable "V" Blocks


Checkmaster SMM - Product Brochure
